The products here are part of DADISICK's brand product line, which is independently developed, manufactured, and sold.
We provide stable, high-quality products and ensure fast delivery.
| Categories | Explosion-proof Inductive Proximity Sensor |
|---|---|
| Brand | DADISICK |
| Model | Explosion-proof Inductive Proximity Sensor | LB08 Pre-wired Non-Shielded | LB08-02NA-ZBF-H, LB08-04NA-ZBF-H |
| Size: | Cylindrical M8 |
| Detection range: | 2mm, 4mm |
| Case material: | Nickel Plated Brass |
| Connection type: | 2M Cable |
| Output method: | NAMUR |
| Degree of protection: | IP67 |
| Operating temperature: | -25°C~+70°C (248~343K) |
| Download |  |
| Update Time | Jul 18,2025 |
Explosion-proof Inductive Proximity Sensor Cylindrical M8 Pre-wired Non-Shielded Series Datasheet |
|||||||
|
Model
|
Output | Sensing distance | Connection | Mounting | Operating voltage | Case material |
|
LB08-02NA-ZBF-H | NAMUR | 2mm | 2 meter cable | Non-shielded | 6-12VDC | Nickel Plated Brass | |
LB08-04NA-ZBF-H | 4mm | ||||||
|
Electrical data
|
|||
|
LED Display
|
No
|
||
|
No-load current
|
>2.2mA(OFF) <1.1mA(ON)
|
||
Switching frequency | 1KHZ | ||
Response time | 0.1ms | ||
Switching hysteresis | <15%（Sr） | ||
Repeat accuracy | <1.0%（Sr） | ||
Degree of protection | IP67 | ||
Operating temperature | -25℃ to +70℃ | ||
Temperature drift | <1%（Sr） | ||
Time delay | <10ms | ||
EMC | RFI>3V/m / EFT>1KV / ESD>4KV (contact) | ||
Sensing surface material | PBT | ||
